The low-voltage foil winding machine is suitable for1KVThe following voltage. The machine can perform lap winding and double winding on two layers of copper foil or aluminum foil. All production parameters are set through the man-machine interface, and the machine runs automatically.

Host unit
1.VFFoil winding unit for controlling stepless speed change
2.Main frame, including foil pressing, insulation edge cutting, photoelectric correction, conductor pulling and other functions.

3.A foil unreeling machine,2Set

4.A deburring device and a foil cleaning device,2Set

5.Feeder:2Set

6.Winder:1Set

7.The invention relates to a paper insulating material uncoiler,2Set

8.An automatic shearing device,2Set

9.The invention relates to full-automatic argon arc welding equipment and a welding machine,1Set
10.A pneumatically positioned end insulation filling system,2Set
11.PLCControl and touch screen operating system
